VACON® NX All-in-One
Application Guide
Index Parameter
P2.2.2.9
AI1 sleep limit
P2.2.2.10
AI1 sleep delay
P2.2.2.11
AI1 joystick offset
Use the Terminal to Function method (TTF) with these parameters, see
1
Remember to place jumpers of block X2 according to the selection (0, 1, 2, or 3). See the User Manual of the product.
2
Table 58: Analog Input 2 (Control Panel: Menu M2 -> G2.2.3)
Index Parameter
P2.2.3.1
(1)
AI2 signal selection
P2.2.3.2
AI2 filter time
P2.2.3.3
(2)
AI2 signal range
P2.2.3.4
AI2 custom minimum setting
P2.2.3.5 AI2 custom maximum setting
P2.2.3.6 AI2 reference scaling, minimum value
P2.2.3.7
AI2 reference scaling, maximum value
P2.2.3.8
AI2 joystick hysteresis
P2.2.3.9
AI2 sleep limit
P2.2.3.10
AI2 sleep delay
P2.2.3.11
AI2 joystick offset
Use the Terminal to Function method (TTF) with these parameters, see
1
Remember to place jumpers of block X2 according to the selection (0, 1, 2 or 3). See the User Manual of the product.
2
Table 59: Analog Input 3 (Control Panel: Menu M2 -> G2.2.4)
Index Parameter
P2.2.4.1
(1)
AI3 signal selection
P2.2.4.2
AI3 filter time
P2.2.4.3
(2)
AI3 signal range
94 | Danfoss A/S © 2023.02
Min Max Unit
0.00 100.00 %
0.00 320.00 s
-100.00 100.00 %
10.626 "Terminal to Function" (TTF) Programming
Min Max Unit
-
0.1 E.10
0.00 320.00 s
-
0 3
-160.00 160.00 %
-160.00 160.00 %
0.00 320.00 Hz
0.00 320.00 Hz
0.00 20.00 %
0.00 100.00 %
0.00 320.00 s
-100.00 100.00 %
10.626 "Terminal to Function" (TTF) Programming
Min Max Unit
-
0.1 E.10
0.00 320.00 s
-
0 3
Multi-purpose Control Application
Default ID Description
-
0.00 385
-
0.00 386
-
0.00 165
Principle)
Default ID Description
-
A.2 388
-
0.10 329
1 325 0 = 0–10 V (0-20mA)
1 = 2–10 V (4–20 mA)
2 = -10V...+10 V
3 = Custom range
-
20.00 326
-
100.00 327
-
0.00 393
-
0.00 394
-
0.00 395
-
0.00 396
-
0.00 397
-
0.00 166
Principle)
Default ID Description
-
0.1 141
0.00 142 0 = No filtering
0 143 0 = 0–10 V (0-20mA)
1 = 2–10 V (4–20 mA)
2 = -10V...+10 V
AB296635287482en-000301 / DPD00903
