P2.7.19 UP Zero frequency load
P2.7.20 Underload protection time limit
P2.7.21 Response to thermistor fault
P2.7.22 Response to fieldbus fault
P2.7.23 Response to slot fault
3.4.9 Autorestart Parameters (Control Panel: Menu M2 -> G2.8)
Table 13: Autorestart Parameters, G2.8
Index Parameter
P2.8.1 Wait time
P2.8.2 Trial time
P2.8.3 Start function
P2.8.4 Number of tries after undervoltage trip
P2.8.5 Number of tries after overvoltage trip
P2.8.6 Number of tries after overcurrent trip
P2.8.7 Number of tries after 4 mA reference trip
P2.8.8 Number of tries after motor temperature fault trip
P2.8.9 Number of tries after external fault trip
P2.8.10 Number of tries after underload fault trip

3.4.10 Keypad Control (Control Panel: Menu M3)

The parameters for the selection of control place and direction on the keypad are listed in this table. See the Keypad control menu in
the User Manual of the product.
Table 14: Keypad Control Parameters, M3
Index Parameter
P3.1 Control place
