Index Parameter
P2.2.17 AI1 custom minimum
setting
P2.2.18 Free analog input, func-
tion
P2.2.19 AI1 inversion
P2.2.20 AI1 filter time
P2.2.21
(3)
AI2 signal selection
P2.2.22
(3)
AI2 signal range
P2.2.23 AI2 custom minimum
setting
P2.2.24 AI2 custom maximum
setting
P2.2.25 AI2 inversion
P2.2.26 AI2 filter time
P2.2.27 Motor potentiometer
ramp time
P2.2.28 Motor potentiometer
frequency reference
memory reset
P2.2.29 Motor potentiometer
PID reference memory
reset
P2.2.30 PID minimum limit
P2.2.31 PID maximum limit
P2.2.32 Error value inversion
P2.2.33 PID reference rising
time
P2.2.34 PID reference falling
time
Danfoss A/S © 2023.02
Min Max Unit Default
–160.00 160.00 % 0.00
–160.00 160.00 % 100.0
-
0 1 0
0.00 10.00 s 0.10
-
0.1 E.10 A.2
-
0 2 1
-160.00 160.00 % 0.00
-160.00 160.00 % 0.00
-
0 1 0
0.00 10.00 s 0.10
0.1 2000.0 Hz/s 10.0
-
0 2 1
-
0 2 0
-1600.0 P2.2.31 % 0.0
P2.2.30 1600.0 % 100.0
-
0 1 0
0.1 100.0 s 5.0
0.1 100.0 s 5.0
PID Control Application
ID Description
-
321
-
322
323 0 = Not inverted
1 = Inverted
-
324
388 0 = 0–20 mA (0–10 V)
1 = 4–20 mA (2–10 V)
2 = Custom range
325 0 = 0–20 mA
1 = 4–20 mA
2 = Customised
-
326
-
327
328 0 = Not inverted
1 = Inverted
329 0 = No filtering
-
331
367 0 = No reset
1 = Reset if stopped or powered down
2 = Reset if powered down
370
-
359
-
360
340 0 = No inversion
1 = Inversion
-
341
-
342
