VACON® NX All-in-One
Application Guide
This parameter is present in VACON
This input is configured as normally open. If a normally closed input is needed, consider using external fault.
10.60 (ID 300) Start/Stop Logic Selection
Location in the menu:
• P2.2.1 (Standard Application, Local/Remote Control Application, Multi-Step Speed Control Application)
• P2.2.1.1 (Multi-Purpose Control Application)
Use this parameter to control the start and stop of the drive with the digital signals.
Table 115: Selections for Parameter ID 300
Selection DIN 1
0 closed contact = start forward
(1)
1
(2)
closed contact = start
open contact = stop
2
closed contact = start
open contact = stop
3 closed contact = start forward (Rising
(3)(4)
edge required to start)
Standard Application and Multi-Step Speed Control Application
4 closed contact = start forward (Rising
edge required to start)
5 closed contact = start (Rising edge re-
quired to start)
open contact = stop
6 closed contact = start (Rising edge re-
quired to start)
open contact = stop
Local/Remote Control Application and Multi-Purpose Control Application
4
closed contact = start forward
5 closed contact = start forward (Rising
edge required to start)
6 closed contact = start (Rising edge re-
quired to start)
open contact = stop
7 closed contact = start (Rising edge re-
quired to start)
Danfoss A/S © 2023.02
NXP drives only.
®
(5)
(5)
(5)
(5)
(5)
(5)
(5)
DIN 2
closed contact = start reverse
closed contact = reverse
open contact = forward
closed contact = start enabled
open contact = start disabled and drive stopped if
running
closed contact = start reverse (Rising edge re-
quired to start)
(5)
closed contact = start reverse (Rising edge re-
quired to start)
(5)
closed contact = reverse
open contact = forward
closed contact = start enabled
open contact = start disabled and drive stopped if
running
closed contact = reference increases (motor poten-
tiometer reference; this parameter is automatically
set to 4 if parameter ID 117 is set to 4 [Application
4]).
closed contact = start reverse (Rising edge re-
quired to start)
(5)
closed contact = start reverse (Rising edge re-
quired to start)
(5)
closed contact = start enabled
Parameter Descriptions
DIN 3
-
-
can be program-
med for reverse
command
-
-
-
can be program-
med for reverse
command unless
selected for DIN 2
-
-
-
-
