VACON® NX All-in-One
Application Guide
Index Monitoring value
These monitoring values can be controlled from the fieldbus.
1
Visible only when the option board installed in the AC drive supports 16 Process data items.
2
Table 47: Digital Input Statuses: ID15 and ID16
Bit
DIN 1/DIN 2/DIN 3 status
b0 DIN 3
b1 DIN 2
b2 DIN 1
Table 48: Digital Input Statuses: ID56 and ID57
Bit
DIN StatusWord 1
b0 DIN: A.1
b1 DIN: A.2
b2 DIN: A.3
b3 DIN: A.4
b4 DIN: A.5
b5 DIN: A.6
b6 DIN: B.1
b7 DIN: B.2
b8 DIN: B.3
b9 DIN: B.4
86 | Danfoss A/S © 2023.02
Multi-purpose Control Application
Unit Form ID
DIN 4/DIN 5/DIN 6 status
DIN 6
DIN 5
DIN 4
DIN StatusWord 2
DIN: C.5
DIN: C.6
DIN: D.1
DIN: D.2
DIN: D.3
DIN: D.4
DIN: D.5
DIN: D.6
DIN: E.1
DIN: E.2
AB296635287482en-000301 / DPD00903
Description
B1 = Stator voltage warn-
ing S1
B2 = Vibration warning S1
B3 = Load warning S1
B5 = Stator current warn-
ing S2
B6 = Stator voltage warn-
ing S2
B7 = Vibration warning S2
B8 = Load warning S2
B10 = Stator current
alarm/fault
B11 = Stator voltage
alarm/fault
B12 = Vibration alarm/
fault
B13 = Load alarm/fault
