VACON® NX All-in-One
Application Guide
10.258 (ID 531) Inching Reference 2
Location in the menu: P2.2.7.28 (Multi-purpose Control Application)
Use this parameter to select the digital input signal that activates the inching reference.
The inputs also start the drive when activated and if there is no Run Request command from anywhere else.
Negative reference is used for reverse direction (see parameters ID 1239 and ID 1240).
The parameter is available for VACON
10.259 (ID 532) Enable Inching
Location in the menu: P2.2.7.26 (Multi-purpose Control Application)
Use this parameter to select the digital input signal that activates the inching function.
Inching is a combination of a start command and preset speeds (ID 1239 and ID 1240) with a ramp time (ID 533).
When using the inching function, the input value must be TRUE set by a digital signal or by setting the value of the parameter to 0.2.
The parameter is available for VACON
10.260 (ID 534) Enable I/f control
Location in the menu: P2.6.14.10 (Multi-Purpose Control application)
Use this parameter to enable I/F-control.
10.261 (ID 550) Fieldbus Data In Selection 9
Location in the menu: P2.9.27 (Multi-purpose Control Application, VACON
Use this parameter to select a parameter or monitoring value to be controlled from the fieldbus.
These parameters are visible only if the option board installed to AC drive supports 16 Process data items.
As the value of these parameters, enter the ID number of the item to control. See
10.262 (ID 551) Fieldbus Data In Selection 10
Location in the menu: P2.9.28 (Multi-purpose Control Application, VACON
Use this parameter to select a parameter or monitoring value to be controlled from the fieldbus.
See 10.261 (ID 550) Fieldbus Data In Selection
10.263 (ID 552) Fieldbus Data In Selection 11
Location in the menu: P2.9.27 (Multi-purpose Control Application, VACON
Use this parameter to select a parameter or monitoring value to be controlled from the fieldbus.
See 10.261 (ID 550) Fieldbus Data In Selection
10.264 (ID 553) Fieldbus Data In Selection 12
Location in the menu: P2.9.30 (Multi-purpose Control Application, VACON
Use this parameter to select a parameter or monitoring value to be controlled from the fieldbus.
See 10.261 (ID 550) Fieldbus Data In Selection
10.265 (ID 554) Fieldbus Data In Selection 13
Location in the menu: P2.9.31 (Multi-purpose Control Application, VACON
Use this parameter to select a parameter or monitoring value to be controlled from the fieldbus.
See 10.261 (ID 550) Fieldbus Data In Selection
10.266 (ID 555) Fieldbus Data In Selection 14
Location in the menu: P2.9.32 (Multi-purpose Control Application, VACON
Use this parameter to select a parameter or monitoring value to be controlled from the fieldbus.
See 10.261 (ID 550) Fieldbus Data In Selection
10.267 (ID 556) Fieldbus Data In Selection 15
Location in the menu: P2.9.33 (Multi-purpose Control Application, VACON
Use this parameter to select a parameter or monitoring value to be controlled from the fieldbus.
238 | Danfoss A/S © 2023.02
NXP drives only.
®
NXP drives only.
®
9.
9.
9.
9.
9.
NXP)
®
Table 46.
NXP)
®
NXP)
®
NXP)
®
NXP)
®
NXP)
®
NXP)
®
AB296635287482en-000301 / DPD00903
Parameter Descriptions
