5.4.3 Input Signals (Control Panel: Menu M2 -> G2.2)
Table 27: Input Signals, G2.2
Index Parameter
P2.2.1
(1)
Place A Start/Stop logic se-
lection
P2.2.2 DIN 3 function
P2.2.3
(2)
AI1 signal selection
P2.2.4
(3)
AI1 signal range
P2.2.5 AI1 custom setting mini-
mum
P2.2.6 AI1 custom setting maxi-
mum
50 | Danfoss A/S © 2023.02
Min Max Unit Default
-
0 6 0
-
0 13 1
-
0.1 E.10 A1
-
0 2 0
-160.00 160.00 % 0.00
-160.00 160.00 % 100.00
Multi-step Speed Control
ID Description
Logic = 0
300
Ctrl sgn 1 = Start forward
Ctrl sgn 2 = Start reverse
Logic = 1
Ctrl sgn1 = Start/ Stop
Ctrl sgn 2 = Reverse
Logic = 2
Ctrl sgn 1 = Start/ Stop
Ctrl sgn 2 = Run enable
Logic = 3
Ctrl sgn 1 = Start pulse (edge)
Ctrl sgn 2 = Stop pulse
Logic = 4
Ctrl sgn 1 = Forward pulse (edge)
Ctrl sgn 2 = Reverse pulse (edge)
Logic = 5
Ctrl sgn 1 = Start pulse (edge)
Ctrl sgn 2 = Reverse pulse
Logic = 6
Ctrl sgn 1 = Start pulse (edge)
Ctrl sgn 2 = Enable pulse
301 0 = Not used
1 = Ext. fault, closing cont.
2 = Ext. fault, opening cont.
3 = Run enable
4 = Acc./Dec. time select.
5 = Force cp. to I/O
6 = Force cp. to keypad
7 = Force cp. to fieldbus
8 = Rvs (if P2.2.1 ≠ 2,3 or 6)
9 = Jogging speed
10 = Fault reset
11 = Acc./Dec. operation prohibit
12 = DC Braking command
13 = Preset speed
-
377
320 0 = 0–10V (0–20 mA)
1 = 2–10 V (4–20 mA)
2 = Custom setting range
-
321
-
322
