Before installing the different size VFDs, please align their top position for the convenience of
later maintenance.
The minimum space of B, D and C is 100mm.
4.2.5 Vertical installation
Note: Windscreen should be added in vertical installation for avoiding mutual impact and insufficient
cooling.
B
D
Figure 4-3 Parallel installation
Figure 4-4 Vertical installation
Warm air
Cool air
B
Wind board
Wind board
-16-
Installation guidelines
C
C
