Replaceable Parts
Hardware
Figure 14-16 Front End Parts - Option 532, 544
Item Description
1 A13 RF Front End Assembly
2 A13A1 Bandpass Filter
A13W1 Cable Assembly, A13J10 to A13A1 Input (Semi Rigid)
A13W2 Cable Assembly, A13J11 from A13A1 Output (Semi Rigid)
3 A12 YTF Preselector
4 J1 2.4 m Input Connector Assembly (Option 532, 544)
5 A11 Low Band Switch Assembly
W3 Cable Assembly, A11J2 to A13J2 (Semi Rigid)
W4 Cable Assembly, A14J740 to A13J4 (Semi Rigid)
Keysight N9010A EXA Service Guide
Keysight Part Number
Refer to Table 14-1
Refer to Table 14-1
Refer to Table 14-1
Refer to Table 14-1
5087-7383
N9030-60011
N9020-60051
N9020-20131
N9020-20156
