Default Setting

area-id: None
router-id: None
hello-interval: 10 seconds
retransmit-interval: 5 seconds
transmit-delay: 1 second
dead-interval: 40 seconds
authentication-key: None
message-digest-key: None
Command Usage
• All areas must be connected to a backbone area (0.0.0.0) to maintain
routing connectivity throughout the autonomous system. If it not
possible to physically connect an area to the backbone, you can use a
virtual link. A virtual link can provide a logical path to the backbone
for an isolated area. You can specify up to 32 virtual links on this
router.
• Any area disconnected from the backbone must include the transit area
ID and the router ID for a virtual link neighbor that is adjacent to the
backbone.
• This router supports up 64 virtual links.
Example
This example creates a virtual link using the defaults for all optional
parameters.
Console(config-router)#network 10.4.0.0 0.255.255.0.0 area 10.4.0.0
Console(config-router)#area 10.4.0.0 virtual-link 10.4.3.254
Console(config-router)#
This example creates a virtual link using MD5 authentication.
Console(config-router)#network 10.4.0.0 0.255.255.0.0 area 10.4.0.0
Console(config-router)#area 10.4.0.0 virtual-link 10.4.3.254
message-digest-key 5 md5 ld83jdpq
Console(config-router)#
Related Commands
show ip ospf virtual-links (4-284)
