CLI - The information displayed by the RIP Statistics screen via the Web
interface can be accessed from the CLI using the following commands.
Console#show rip globals
RIP Process: Enabled
Update Time in Seconds: 30
Number of Route Change: 4
Number of Queries: 0
Console#show ip rip configuration
Interface
--------------- --------------- ------------- -------------- ------------------
10.1.0.253
10.1.1.253
Console#show ip rip status
Interface
--------------- --------------- -------------- ---------------
10.1.0.253
10.1.1.253
Console#show ip rip peer
--------------- ------------ --------- --------------- --------------
10.1.0.254
10.1.1.254
Console#

Configuring the Open Shortest Path First Protocol

Open Shortest Path First (OSPF) is more suited for large area networks
which experience frequent changes in the links. It also handles subnets
much better than RIP. OSPF protocol actively tests the status of each link
to its neighbors to generate a shortest path tree, and builds a routing table
based on this information. OSPF then utilizes IP multicast to propagate
routing information. A separate routing area scheme is also used to further
reduce the amount of routing traffic.
Note: The OSPF protocol implemented in this device is based on
Version 2 (RFC 2328). It also supports Version 1 (RFC 1583)
compatibility mode to ensure that the same method is used to
calculate summary route costs throughout the network when older
3-186
S
WITCH
SendMode
rip1Compatible
rip1Compatible
RcvBadPackets
Peer UpdateTime
4610
4610
ReceiveMode
RIPv1Orv2
RIPv1Orv2
RcvBadRoutes
0 0
0 0
Version RcvBadPackets
2
2
Poison Authentication
SplitHorizon noAuthentication
SplitHorizon noAuthentication
SendUpdates
60
63
RcvBadRoutes
0
0
4-242
4-242
4-242
4-242
0
0
