Tiger Switch 10/100/1000
4 expansion slots to configure flexible network
One built-in intelligent module with RS-232 console port
Supports half-duplex mode for backpressure, and
full-duplex for flow-control
Store-and-Forward switching architecture for abnormal
packet filtering
SNMP management
Console and Telenet management
Port trunking supported
IGMP supported
Port Mirror
MIB II and Private MIB supported
Port Security
Installation Guide
SMC6704M
1
Advertisement
Table of Contents
Related Manuals for SMC Networks 6704FMSC
Summary of Contents for SMC Networks 6704FMSC
-
Page 1: Installation Guide
Tiger Switch 10/100/1000 4 expansion slots to configure flexible network One built-in intelligent module with RS-232 console port Supports half-duplex mode for backpressure, and full-duplex for flow-control Store-and-Forward switching architecture for abnormal packet filtering SNMP management Console and Telenet management Port trunking supported IGMP supported Port Mirror... -
Page 2: Limited Warranty
All SMC products carry a standard 90-day limited warranty from the date of purchase from SMC or its Authorized Reseller. SMC may, at its own discretion, repair or replace any product not operating as warranted with a similar or functionally equivalent product, during the applicable warranty term. - Page 3 Any product returned to SMC without a valid Return Material Authorization (RMA) number clearly marked on the outside of the package will be returned to customers at customer’s expense. For warranty claims within North America, please call our toll-free customer support number at (800) 762-4968.
- Page 4 NOTHING IN THIS WARRANTY SHALL BE TAKEN TO AFFECT YOUR STATUTORY RIGHTS. * SMC will provide warranty service for one year following discontinuance from the active SMC price list. Under the limited lifetime warranty, internal and external power supplies, fans, and cables are covered by a standard one-year warranty from date of purchase.
-
Page 5: Table Of Contents
LIMITED WARRANTY....................2 1. Introduction ..................6 2. Product Overview ..............10 3. Network Configuration ...........16 4. Connecting to the Network ........20 5.Web-Based Management ..........33 6.SNMP Management ..............55 7.Product Specifications ............57 Appendix A. Internet Explorer Setting ................59 Appendix B. VLAN Setting..................63 Appendix C. Technical Support and Service ...............68... -
Page 6: Introduction
1. Introduction Welcome to the World of Switching-Network. In modern business society, communication and information sharing are fundamental to our lifestyle. Computer networks are one of the fastest means of communication. Congratulations on purchasing the Modular Switch. This Modular Switch is a combination of 4-slot host cabinet and optional 4 kinds of media modules. -
Page 7: Key Features
With its build-in Web-based Management, managing and configuring the Modular Switch becomes easier. From cabinet management to port-level control and monitoring, you can visually configure and manage your network via Web Browser. Just click your mouse instead of typing cryptic command strings. However, the Modular Switch can also be managed via Telnet, Console, or third-party SNMP Management. -
Page 8: Management Methods
Intelligent Module Features Web-Based Management SNMP Management Console and Telnet Management IEEE 802.1Q Tagging VLAN ( Up to 4095 VLANs ) IEEE 802.1d Spanning Tree Protocol ( STP ) Statistic Address Table for manual address-addition Port Trunking supported IGMP supported Broadcast Storm Filter Port Mirror Web Browser Security... -
Page 9: Snmp Network Management
Web-based Management The Modular Switch provides an embedded HTML web site residing in flash memory. It offers advanced management features and allow users to manage the Modular Switch from anywhere on the network through a standard browser such as Microsoft Internet Explorer. For more information, See Section 5 Web-Based Management. -
Page 10: Product Overview
Modular Switch Rubber Feet Rack-mounted Kit RS-232 cable User Guide Power Cord Figure 1-2. Package Contents Compare the contents of your Modular Switch package with the standard checklist above. If any item is missing or damaged, please contact your local dealer for service. 2. -
Page 11: Physical Description
Physical Description The physical dimensions of the HomePNA 312M are: 440mmx 227mm x 67mm ( Lx Wx H ) The Modular Switch is a modular unit, and its chassis contains four slots. All optional models come with the built-in CPU modules. The LEDs are located on the front panel of the Switch to allow you to monitor the operation and performance at a glance. -
Page 12: Led Indicators
LED Indicators All LED status indicators are located on the FRONT panel of the switch. They provide a real-time indication of system and operational status. The ports for connections to other devices and networks are also on the front panels. Status Meaning Power... -
Page 13: Static Address
Software Concepts Static Address This feature allows you to enter the addresses that will not be aged out. It can confine users on certain ports specified by the system manager, so that they cannot switch to other ports. Spanning Tree Spanning Tree Protocol (STP) is an industry standard that prevents loops configurations in switched networks. -
Page 14: Port Mirror
aggregate several ports into one single group. Additionally, it may be more cost-effective to trunk multiple lower speed links than to underutilize a gigabit port. Available copper links and supported distances are more pervasive for lower speed links. For example, 100Mbps NICs and switch ports are less expensive than 1Gbps equipment. -
Page 15: Port Security
received a similar request to that group. It then propagates the service request on to any neighboring multicast switch to ensure that it will continue to receive the multicast service. Port Security Port Security allow you to restrict specific MAC addresses to reside in some port. -
Page 16: Network Configuration
3. Network Configuration This chapter provides 3 network configuration examples by using the Modular Switch: Collapsed Backbone Application Departmental Bridge Application Virtual LAN (VLAN) Application The switch provides versatile configuration options for the network. It is ideally suited as a workgroup or segment switch in a network; it aggregate traffic from workgroup switches, or provide dedicated 100Mbps to servers with bandwidth-intensive applications. -
Page 17: Departmental Bridge
IEEE 802.3z ( Gigabit Ethernet ) compliant hub. This switch can also cooperate with a wide range of networking devices (e.g., firewall routers and printer servers) added to the network. Figure 3-1. Collapsed Backbone Application Departmental Bridge For enterprise networks where large data broadcasts are constantly processed, this switch is an ideal solution for department users to connect to the corporate backbone. - Page 18 Figure 3-2. Departmental Bridge Application NOTE: Full-duplex operation only applies to point-to-point access (for example, when attaching the switch to a workstation, server, or another switch). When connecting to hubs, use a standard cascaded connection set for half-duplex operation. IEEE 802.1Q VLAN Application The switch support up to 4095 port-based 802.1Q-compatible virtual LANs (VLANs).
- Page 19 to a segment that is a single broadcast domain. Packets received in one VLAN can only be forwarded within that VLAN. VLAN allows the grouping of end stations logically, based not on physical location but on business policies such as job function or department.
-
Page 20: Connecting To The Network
Figure 3-4. Shared Server In this example, stations on different VLANs share resources. As a result, VLAN 1 and VLAN 2 can access VLAN 3 for printing. The broadcasts from ports configured in VLAN3 can be seen by all VLAN port members of VLAN3. -
Page 21: Mounting The Switch
PCs with 10/100/1000Mbps Ethernet cards: Your PC must have a standard Ethernet interface to connect to the switch. UTP cable with RJ-45 connector: Check if the cable and connectors work properly. Fiber cable with SC/ST/MT-RJ/VF-45 connector: Check if the cable and connector types are correct. A power outlet: 100 to 240V AC at 50 to 60 Hz. -
Page 22: Rack Mounting
B. Remove adhesive backing from your Rubber Feet. C. Apply the Rubber Feet to each corner on the bottom of the Switch. These footpads can prevent the Switch from shock/vibration. Figure 4-1. Attaching Rubber Feet to each corner on the bottom of the Switch Rack Mounting The Modular Switch come with a rack-mounted kid and can be mounted in an EIA standard size, 19-inch Rack. - Page 23 Figure 4-2. Figure 2-4. Attach mounting brackets with screws B. After attached both mounting brackets, position the Switch in the rack by lining up the holes in the brackets with the appropriate holes on the rack. Secure the Switch to the rack with a screwdriver and the rack-mounting screws.
-
Page 24: Connecting The Switch
Power On After all network cables are connected, plug the power cord into the power socket on the back panel and the other end into a power outlet. Turn the power on using the power switch on the back panel. Check the front panel Power indicator to see if power is properly supplied. - Page 25 Figure 4-4. Connecting the MaxSwitch to a terminal via RS-232 cable After connected to the Console port, turn on the PC or terminal and configure its communications parameters to match the following default characteristics of the console port: Baud Rate: 9600 bps Start Bit: 1 Data Bits: 8 Stop Bit: 1...
-
Page 26: Assigning Ip Address
parameter settings, press Enter on your keyboard and the Main Menu appears. Figure 4-6. The Main Menu Assigning IP Address After you have attached a terminal or PC with emulation software and you are ready to make a connection using a web browser. You have to firstly assign IP information to the switch. - Page 27 Figure 4-7. The Device Settings page Select IP Address on the Device page, and enter a unique IP address for the switch, and press Enter. ( Default IP address is 192.168.16.1 ) Select Subnet Mask on the Device page, and enter the subnet mask ( IP Netmask ) address, and press Return.
-
Page 28: Port Setting
Port Setting This function is for port speed setup. For example, type “1” and “2” to select port 2 of modular 1. a. More function to choice after typing 1, or 2... - Page 29 b. Pick any number you need to set up, for example, the option 2 is for the Full or Half mood setting. Address table User can view the node’s MAC address table of system, per module or per port, that attached on the device.
-
Page 30: Spanning Tree Protocol
Spanning Tree Protocol Spanning tree is a link management protocol that provides path redundancy while preventing undesirable loops in the network. Broadcast Storm Filter... - Page 31 IGMP Internet Group Multicasting Protocol (IGMP) is used to support real-time applications such as video conferencing or streaming audio. (2 modes) VLAN Mode...
-
Page 32: Secure Ip For Telnet And Http
VLAN For Cpu(2 VLANs) Secure IP for Telnet and HTTP The IP security is for Telnet and HTTP , if device is installed in a internet environment , switch may be attach by Hacker, then the system maybe will crash, for prevent this status, you can enable the function and setting the IP address, it provides four IP address, only authorized IP address can manage device. -
Page 33: Web-Based Management
5.Web-Based Management This section introduces the configuration and functions of the Web-Based management. About Web-based Management Inside the CPU board of the Modular Switch exists an embedded HTML web site residing in flash memory. It offers advanced management features and allow users to manage the Switch from anywhere on the network through a standard browser such as Microsoft Internet Explorer. -
Page 34: System Login
network bandwidth consumption, enhance access speed and present an easy viewing screen. Note: By default, IE4.0 does not allow Java Applets to open sockets. The user has to explicitly modify the browser setting to enable Java Applets to use network ports. ( See Appendix A: for the means to modify the setting ) And you don’t need to change any configuration if you use Netscape browser. -
Page 35: System Configuration
System Configuration Figure 5-2 The Home Page Screen Home The Home page displays the configuration of the Modular Switch. System Name : An administratively-assigned name of the managed unit, can be modified in SNMP page. System Location : The physical location of this managed unit ( e.g., laboratory, 3 floor ), can be modified in SNMP page. - Page 36 Default Gateway : The default gateway of the managed unit, can be modified in IP Config page. MAC Address : The MAC address of the managed unit, read only. Firmware Version : The firmware version of the management unit, read only. You can on-line upgrade the new firmware if the new version is released.
- Page 37 Any four of the following modules can be installed to the Switch. 8-port auto-sensing 10/100Base-TX Switch Module 2-port 100Base-FX (SC/ST) Fiber Module 4-port 100Base-FX (SC/ST) Fiber Module 2-port 100Base-FX (MT-RJ/VF-45) Fiber Module 4-port 100Base-FX (MT-RJ/VF-45) Fiber Module 8-port 100Base-FX (MT-RJ/VF-45) Fiber Module 1-port Gigabit 1000Base-F ( SX/LX ) Fiber Module 1-port Gigabit 1000Base-F ( MT-RJ ) Fiber Module 1-port Gigabit 1000Base-T Switch Module...
- Page 38 Duplex: full or half duplex Tagged: whether a packet transmitted with VLAN tagged or not Default VLAN ID: if a packet is received without VLAN tagged, then the Default VLAN ID is used to classify this packet to that VLAN Note: memorial note for this port, max length is 16 characters Note: if you want to set multiple VLANs, we suggest that you set Default VLAN ID for each port first then set VLAN in the VLAN...
- Page 39 that port Collision: the total number of collisions that occurred during reception and transmission You can clear 8 counters of some ports by select the corresponding "Clear" check boxes then press "Clear" button. To clear all counters of all ports, press the "Select All" button then "Clear" button. Statistics 2 The statistics 2 page displays the detailed packet size information...
- Page 40 VLAN ( Virtual LAN ) A port-based VLAN is a group of switch ports designated by the switch as belonging to the same broadcast domain. If a broadcast packet is received from a port, it will forward this broadcast packet only to those ports belonging to the same VLAN.
- Page 41 Enter the VLAN index in the "VLAN" edit box then press "Go to" button You can add, edit and remove port members of each VLAN and then finally press "Apply" button only once to configure the desired VLANs you want. Note: if you want to set multiple VLANs, we suggest that you set Default VLAN ID for each port first in Ports page.
- Page 42 ( Note: Make sure trunking ports are in the same VLAN group. ) STP (Spanning Tree Protocol) Spanning tree is a link management protocol that provides path redundancy while preventing undesirable loops in the network. For Layer 2 Ethernet network to function properly, only one active path must exist between two stations.
- Page 43 MAC Address: the MAC address of the root switch Root Max Age: the amount of time (in seconds) protocol information received on a port is stored by the root switch Root Hello Time: how often the root switch broadcasts Hello message to other switches Root Forward Delay: the amount of time a port will remain in the listening and learning states before entering the forwarding state...
- Page 44 Path Cost: the cost of this port. The smaller this value, the higher cost this port has. 4 for Gigabit Ethernet and 10 for Fast Ethernet and FDDI Root Cost: The cost to the root. Figure 5-8-1 The STP lower page Note: when you enable the spanning tree protocol, because all ports in the switch will listen and learn, you may lose communication to the switch you are managing.
- Page 45 Port Security Port Security allow you to restrict specific MAC addresses to reside in some port. For example, a dummy hub is attached to some port for extension, and you just only allow 2 users to access this port at the same time, you can use the port security window to set the parameters.
- Page 46 Priority There are two priority queues ( high and low ) on each port. Each port arbitrates between two transmit queues ( high and low priority ). The arbitration uses weighted round-robin between the high and low priority queues, and you can adjust this weight. Programmable Mapping of 802.1p to Internal Priority The received packets with 802.1q tag are assigned priority according to a flexible (fixed for the old 48310 and 48320 module)
- Page 47 Priority 2 Each port can parse the header of an incoming IPv4 header and identify the Type-Of-Service byte (TOS field). This is extremely important with the deployment of Microsoft Windows 2000 and the emerging DiffServ standard, which marks Voice-Over-IP and other real-time traffic using this field.
- Page 48 enabled, this switch only directs the multicast data packets to the ports where needed, saving bandwidth. If "Forward with high priority" option is enabled, then the IP multicast traffic will have a higher priority than other traffic. Figure 5-12 The IGMP page Static Address You can lock a certain MAC address ( associated with a host, ) to a certain port.
- Page 49 with from the Port drop-down box. 3. Select VLAN Groups. 4. Click <<Add…<<. Note: You can apply the previous steps to add/remove Static Address manually. Figure 5-13 The Static Address page Broadcast Storm Filter Excessive broadcast packets (broadcast storms) can be filtered in our managed switch by enabling the "Broadcast Storm Filtering"...
- Page 50 Figure 5-14 The Broadcast Storm Filter page Port Mirror If you want to monitor all receive and transmit packets of one port. You can do the following: Choose the monitored port in "Mirror Source Port" choice box in the corresponding mirror source module. Only one port can be monitored in one module at the same time Choose the corresponding target module, port in "Mirror Target Module"...
- Page 51 Figure 5-15 The Port Mirror page IP Config You can change the IP address, subnet mask and default gateway of the managed node. (You can also do that from RS232 console). Enter the IP address, subnet mask and default gateway in the corresponding edit box.
- Page 52 Press the "Apply" button You should reboot system to let your settings take effect if you have changed one of the IP address, subnet mask and default gateway. Figure 5-16 The IP Config page SNMP To set system name, system location and system contact, you can type the desired text string in the corresponding edit box.
- Page 53 Figure 5-17 The SNMP page Save and Reboot Save You can save current settings by click the "Current Settings" checkbox then press the "Apply" button next to the checkbox. You should reboot the system so that your current settings will take effect.
- Page 54 If you want to reboot system, click the "Reboot System" checkbox then press the "Apply" button next to the checkbox. Please wait a moment (about 25 seconds) then continue to operate this home page. Figure 5-18 Save & Reboot page Upgrade You can on-line upgrade the firmware of the managed unit.
-
Page 55: Snmp Management
Figure 5-19 Upgrade page After you have successfully upgraded the new firmware, please reboot the system so that the new firmware will take effect. Note: If you can't upgrade your new firmware successfully, try again ( don't shut down the switch ). 6.SNMP Management This section describes how to configure and manage the switch by accessing Management Information Base (MIB) objects with the... - Page 56 SNMP Management The switch MIB options are accessible through SNMP. Instead of defining a large set of commands, SNMP performs all operations using the “GET”, “GETNEXT” and “SET” commands. The SNMP agent that resides on the switch can respond to MIB-related queries being sent by the network management software.
-
Page 57: Product Specifications
Modify and store values of SNMP objects in a network device. The reply to a GET, GETNEXT, and SET RESPONSE commands sent by a SNMP agent TRAP A message sent by an SNMP agent to an SNMP manager indicating some event occurred. Table 6-1. - Page 58 Per Port: 8 port Auto-sensing: LED Indicators 100M, LK/ACT, FD/COL ( 3 LEDs ) 100M Fiber: LK/ACT, FD/COL ( 2 LEDs ) Gigabit : LK, ACT, FD, COL ( 4 LEDs ) Per Unit : Power, Diag Network Cables 10Base-T: 2-pair UTP/STP Cat. 3, 4, 5 cable EIA/TIA-568 (100m ) 100Base-TX: 2-pair UTP/STP Cat.
-
Page 59: Appendix A. Internet Explorer Setting
Appendix A. Internet Explorer Setting If using IE 4.x and later version, you have to modify the browser setting to enable Java applets to use network ports. We use Internet Explorer 5.0 as demonstrational sample: We first select ”Internet Optional..” under “Tools” of function bar, then follow the step-by-step execution. - Page 60 Step 3 : click “ sites ” Step 4 : add the IP of the Modular Switch to the zone, click " Add " Step 5: Disable left-bottom box – Require server verification for all sites in this zone, then click "OK "...
- Page 61 Step 6: go back to Internet Options, then click “ Customer Level ” Step 7: pull down rolling to find “Java ” Step 8: select “ Custom ” under “Java ”...
- Page 62 Step 9:select”Java Custom Setting” Step 10: select “Edit Permissions”...
-
Page 63: Appendix B. Vlan Setting
Step 11: select “Enable” under ”Unsigned Content”, Appendix B. VLAN Setting In Appendix B, We provide two examples of VLAN management on VLAN Group Configuration. The two examples will show you how to Configure VLAN Group: Port-Based VLAN The following example shows you how to create 2 Port-based VLANs including two overlapping ports. - Page 64 MaxSwitch II M G R OU P 1 VID= 1 G R OU P 2 VID= 2 Ports--> ( 1~ 4) Port--> ( 5~ 8 ) Connect to Port 3 Connect to Port 8 Connect TO Port Work-Station A Work-Station B F i le Server Before you begin to create new VLAN Group, you need to set PVID number on Ports page as below:...
- Page 65 Remember to click “ Apply “ button after you finish your setting. Then, return to VLAN page, and the screen displays as below: Afterwards, you click to select Port 4 and Port 5 for the purpose of overlapping. Remember to click “ Apply “ button after you finish your setting.
- Page 66 Tagging ( Mac Address based ) VLAN This method of tagging is defined in the IEEE 802.1Q standard, to configure switch port by the tagging function that allows the port to transmit tagging frame. VLAN Tagging can only be used if the devices at both ends of a link support IEEE 802.1Q.
- Page 67 Then, return to VLAN page, you will see the screen as below. Continue to press ¡ n ¡ n button and the next page VLAN 3 appears Click the checkbox on Port 1, Module 1. Remember to click “ Apply “ button after you finish your setting. Now, you have finished one Tagging VLAN setting.
-
Page 68: Appendix C. Technical Support And Service
Wide Web site: http://www.smc.com/ Online Technical Services SMC offers worldwide product support 24 hours a day, 7 days a week, through the following online systems: _ World Wide Web site World Wide Web Site To access the latest networking information on the... - Page 69 If you are unable to contact your network supplier, see the following section on how to contact SMC. Support from SMC If you are unable to obtain assistance from the SMC online technical resources or from your network supplier, SMC offers technical telephone support services.
