Map Ip Port (Interface Configuration) - SMC Networks SMC6724L3 Management Manual

C L
OMMAND INE
Example
The following example shows how to enable TCP/UDP port mapping
globally:
Console(config)#map ip port
Console(config)#

map ip port (Interface Configuration)

Use this command to set IP port priority (i.e., TCP/UDP port priority).
Use the no form to remove a specific setting.
Syntax
map ip port port-number cos cos-value
no map ip port port-number
• port-number - 16-bit TCP/UDP port number. (Range: 0-65535)
• cos-value - Class-of-Service value (Range: 0-7)
Default Setting
None
Command Mode
Interface Configuration (Ethernet, Port Channel)
Command Usage
• The precedence for priority mapping is IP Port, IP Precedence or IP
DSCP, and default switchport priority.
• This command sets the IP port priority for all interfaces.
Example
The following example shows how to map HTTP traffic to CoS value 0:
Console(config)#interface ethernet 1/5
Console(config-if)#map ip port 80 cos 0
Console(config-if)#
4-188
