CLI – This example sets the authentication mode to enable dot1x on
port 2.
Console(config)#interface ethernet 1/2
Console(config-if)#dot1x port-control auto
Console(config-if)#

Displaying 802.1x Statistics

This switch can display statistics for dot1x protocol exchanges for any
port.
Statistical Values
Parameter
Rx EXPOL Start
Rx EAPOL Logoff
Rx EAPOL Invalid
Rx EAPOL Total
Rx EAP Resp/Id
Rx EAP Resp/Oth
Rx EAP LenError
Rx Last EAPOLVer
Rx Last EAPOLSrc
Tx EAPOL Total
Description
The number of EAPOL Start frames that have been
received by this Authenticator.
The number of EAPOL Logoff frames that have been
received by this Authenticator.
The number of EAPOL frames that have been received
by this Authenticator in which the frame type is not
recognized.
The number of valid EAPOL frames of any type that
have been received by this Authenticator.
The number of EAP Resp/Id frames that have been
received by this Authenticator.
The number of valid EAP Response frames (other than
Resp/Id frames) that have been received by this
Authenticator.
The number of EAPOL frames that have been received
by this Authenticator in which the Packet Body Length
field is invalid.
The protocol version number carried in the most
recently received EAPOL frame.
The source MAC address carried in the most recently
received EAPOL frame.
The number of EAPOL frames of any type that have
been transmitted by this Authenticator.
