• Root Hold Time – The interval (in seconds) during which no more than
two bridge configuration protocol data units shall be transmitted by this
node.
Web – Click Spanning Tree, STA Information.
CLI – This command displays global STA settings, followed by settings
for each port.
Console#show spanning-tree
Bridge-group information
--------------------------------------------------------------
Spanning tree mode
Spanning tree enable/disable
Priority
Bridge Hello Time (sec.)
Bridge Max Age (sec.)
Bridge Forward Delay (sec.)
Root Hello Time (sec.)
Root Max Age (sec.)
Root Forward Delay (sec.)
Designated Root
Current root port
Current root cost
Number of topology changes
Last topology changes time (sec.):435571
Transmission limit
Path Cost Method
.
.
.
Note: The current root port and current root cost display as zero when
this device is not connected to the network.
S T
PANNING REE
:RSTP
:enable
:32768
:2
:20
:15
:2
:20
:15
:32768.0000ABCD0000
:0
:0
:9
:3
:long
