C
ONFIGURING THE
• Netmask – Network mask for the associated IP subnet. This mask
identifies the host address bits used for routing to specific subnets.
• Next Hop – The IP address of the next hop (or gateway) in this route.
• Protocol – The protocol which generated this route information.
(Options: local, static, RIP, OSPF)
• Metric – Cost for this interface.
• Entry Count – The number of table entries.
Web - Click IP, Routing, Routing Table.
CLI - This example shows routes obtained from various methods.
Console#show ip route
Ip Address
--------------- --------------- --------------- -------- ------ ---------
0.0.0.0
10.1.0.0
10.1.1.0
Total entries: 3
Console#
3-174
S
WITCH
Netmask
0.0.0.0
255.255.255.0
255.255.255.0
Next Hop Protocol Metric Interface
10.1.0.254 static
10.1.0.253 local
10.1.0.254
4-228
1
1
RIP 2
1
1
1
