C
ONFIGURING THE
CLI – The following example enables LACP for ports 17 and 18. Just
connect these ports to two LACP-enabled trunk ports on another switch
to form a trunk.
Console(config)#interface ethernet 1/17
Console(config-if)#lacp
Console(config-if)#exit
Console(config)#interface ethernet 1/18
Console(config-if)#lacp
Console(config-if)#end
Console#show interfaces status port-channel 1
Information of Trunk 1
Basic information:
Port type: 100tx
Mac address: 22-22-22-22-22-2d
Configuration:
Name:
Port admin status: Up
Speed-duplex: Auto
Capabilities: 10half, 10full, 100half, 100full,
Flow control status: Disabled
Current status:
Created by: Lacp
Link status: Up
Port operation status: Up
Operation speed-duplex: 100full
Flow control type: None
Member Ports: Eth1/17, Eth1/18,
Console#

Statically Configuring a Trunk

Command Usage
• When configuring static trunks, you
may not be able to link switches of
different types, depending on the
manufacturer's implementation.
However, note that the static trunks
on this switch are Cisco EtherChannel
compatible.
• To avoid creating a loop in the network,
be sure you add a static trunk via the
configuration interface before connecting the ports, and also disconnect
the ports before removing a static trunk via the configuration interface.
3-82
S
WITCH
statically
configured
active
links
4-119
4-139
4-128
