SMC Networks SMC6724L3 Management Manual page 176

C
ONFIGURING THE
Web – Click Priority, IP Precedence Priority. Select a port or trunk from
the Interface field. Select an entry from the IP Precedence Priority Table,
enter a value in the Class of Service Value field, and then click Apply.
* Mapping specific values for IP Precedence is implemented as an interface
configuration command, but any changes apply to the all interfaces on the switch.
CLI – The following example globally enables IP Precedence service on
the switch, maps IP Precedence value 1 to CoS value 0 (on port 1), and
then displays the IP Precedence settings.
Console(config)#map ip precedence
Console(config)#interface ethernet 1/1
Console(config-if)#map ip precedence 1 cos 0
Console(config-if)#end
Console#show map ip precedence ethernet 1/5
Precedence mapping status: disabled
Port
--------- ---------- ---
Eth 1/ 1
Eth 1/ 1
Eth 1/ 1
Eth 1/ 1
Eth 1/ 1
Eth 1/ 1
Eth 1/ 1
Eth 1/ 1
Console#
* Mapping specific values for IP Precedence is implemented as an interface
configuration command, but any changes apply to the all interfaces on the switch.
3-128
S
WITCH
Precedence COS
0 0
1 0
2 2
3 3
4 4
5 5
6 6
7 7
4-189
4-119
4-189
4-194
