C L
OMMAND INE
Default Setting
The list below shows the default priority mapping.
IP Precedence Value
Command Mode
Interface Configuration (Ethernet, Port Channel)
Command Usage
• The precedence for priority mapping is IP Port, IP Precedence or IP
DSCP, and default switchport priority.
• IP Precedence values are mapped to default Class of Service values on
a one-to-one basis according to recommendations in the IEEE 802.1p
standard, and then subsequently mapped to the four hardware priority
queues.
• This command sets the IP Precedence for all interfaces.
Example
The following example shows how to map IP precedence value 1 to CoS
value 0:
Console(config)#interface ethernet 1/5
Console(config-if)#map ip precedence 1 cos 0
Console(config-if)#
4-190
I
NTERFACE
0
1
2
3
4
5
6
7
CoS Value
0
1
2
3
4
5
6
7
