(page 4-71), and Port-control (page 4-68). It also displays the following
information:
- Status– Authorization status (authorized or unauthorized).
- Supplicant– MAC address of authorized client.
• Authenticator State Machine
- State– Current state (including initialize, disconnected, connecting,
authenticating, authenticated, aborting, held, force_authorized,
force_unauthorized).
- Reauth Count– Number of times connecting state is re-entered.
• Backend State Machine
- State– Current state (including request, response, success, fail,
timeout, idle, initialize).
- Request Count– Number of EAP Request packets sent to the
Supplicant without receiving a response.
- Identifier(Server)– Identifier carried in the most recent EAP
Success, Failure or Request packet received from the Authentication
Server.
• Reauthentication State Machine
- State– Current state (including initialize, reauthenticate).
Example
Console#show dot1x
Global 802.1X Parameters
reauth-enabled: yes
reauth-period:
quiet-period:
tx-period:
supp-timeout:
server-timeout: 30
reauth-max:
max-req:
802.1X Port Summary
Port Name
1
2
. .
.
25
26
300
350
300
30
2
2
Status
disabled ForceAuthorized
disabled ForceAuthorized
disabled ForceAuthorized
enabled
A
UTHENTICATION
Mode Authorized
Auto
C
OMMANDS
n/a
n/a
yes
yes
4-73
