C
ONFIGURING THE
Click Priority, IP Port Priority. Select a port or trunk from the Interface
field. Enter the port number for a network application in the IP Port
Number box and the new CoS value in the Class of Service box, and then
click Add IP Port.
* Mapping specific values for IP Port Priority is implemented as an interface
configuration command, but any changes will apply to the all interfaces on the
switch.
CLI – The following example globally enables IP Port Priority service on
the switch, maps HTTP traffic (on port 1) to CoS value 0, and then
displays the IP Port Priority settings.
Console(config)#map ip port
Console(config)#interface ethernet 1/1
Console(config-if)#map ip port 80 cos 0
Console(config-if)#end
Console#show map ip port ethernet 1/5
TCP port mapping status: disabled
Port
--------- -------- ---
Eth 1/ 1
Console#
* Mapping specific values for IP Port Priority is implemented as an interface
configuration command, but any changes will apply to the all interfaces on the
switch.
3-132
S
WITCH
Port no. COS
80 0
4-187
4-119
4-188
4-193
