Saving Or Restoring Configuration Settings - SMC Networks SMC6724L3 Management Manual

If you download to a new destination file, then select the file from the
drop-down box for the operation code used at startup, and click Apply
Changes. To start the new firmware, reboot the system via the System/
Reset menu.
CLI – Enter the IP address of the TFTP server, select "config" or
"opcode" file type, then enter the source and destination file names, set the
new file to start up the system, and then restart the switch.
Console#copy tftp file
TFTP server ip address: 10.1.0.19
Choose file type:
1. config:
Source file name: M100000.bix
Destination file name: V1.0
\Write to FLASH Programming.
-Write to FLASH finish.
Success.
Console#config
Console(config)#boot system opcode:V1.0
Console(config)#exit
Console#reload

Saving or Restoring Configuration Settings

You can upload/download configuration settings to/from a TFTP server.
The configuration file can be later downloaded to restore the switch's
settings.
Command Attributes
• TFTP Server IP Address – The IP address of a TFTP server.
• File Name — The configuration file name should not contain slashes (\
or /), the leading letter of the file name should not be a period (.), and the
maximum length for file names on the TFTP server is 127 characters or
2. opcode: <1-2>: 2
