C
ONFIGURING THE
port connected to a hub unless it is actually required to solve a
problem. Otherwise back pressure jamming signals may degrade
overall performance for the segment attached to the hub.)
(Default: Autonegotiation enabled; Advertised capabilities for
100BASE-TX – 10half, 10full, 100half, 100full; 1000BASE-T – 10half,
10full, 100half, 100full, 1000full; 1000BASE-SX/LX/LH – 1000full)
• Trunk – Indicates if a port is a member of a trunk. To create trunks and
select port members, see "Trunk Configuration" on page 3-79.
Note: Auto-negotiation must be disabled before you can configure or
force the interface to use the Speed/Duplex Mode or Flow Control
options.
Web – Click Port, Port Configuration or Trunk Configuration. Modify the
required interface settings, and click Apply.
CLI – Select the interface, and then enter the required settings.
Console(config)#interface ethernet 1/13
Console(config-if)#description RD SW#13
Console(config-if)#shutdown
.
Console(config-if)#no shutdown
Console(config-if)#no negotiation
Console(config-if)#speed-duplex 100half
Console(config-if)#flowcontrol
.
Console(config-if)#negotiation
Console(config-if)#capabilities 100half
Console(config-if)#capabilities 100full
Console(config-if)#capabilities flowcontrol
3-68
S
WITCH
4-119
4-119
4-125
4-121
4-120
4-124
4-122
