• Type – Allows you to select which traffic to mirror to the target port, Rx
(receive), Tx (transmit), or Both.
• Target Port – The port that will "duplicate" or "mirror" the traffic on
the source port.
Web – Click Port, Mirror. Specify the source port, the traffic type to be
mirrored, and the monitor port, then click Add.
CLI – Use the interface command to select the monitor port, then use the
port monitor command to specify the source port. Note that default
mirroring under the CLI is for both received and transmitted packets.
Console(config)#interface ethernet 1/10
Console(config-if)#port monitor ethernet 1/13
Console(config-if)#

Showing Port Statistics

You can display standard statistics on network traffic from the Interfaces
Group and Ethernet-like MIBs, as well as a detailed breakdown of traffic
based on the RMON MIB. Interfaces and Ethernet-like statistics display
errors on the traffic passing through each port. This information can be
used to identify potential problems with the switch (such as a faulty port or
unusually heavy loading). RMON statistics provide access to a broad range
of statistics, including a total count of different frame types and sizes
