• Remove – Removes a VLAN group from the current list. If any port is
assigned to this group as untagged, it will be reassigned to VLAN group
1 as untagged.
Web – Click VLAN, VLAN Static List. To create a new VLAN, enter the
VLAN ID and VLAN name, mark the Enable checkbox to activate the
VLAN, and then click Add.
CLI – This example creates a new VLAN.
Console(config)#vlan database
Console(config-vlan)#vlan 2 name R&D media ethernet state active
Console(config-vlan)#end
Console#show vlan
VLAN Type
---- ------- ---------------- --------- ----------------------------------
1 Static
2 Static
Console(config-vlan)#

Adding Static Members to VLANs (VLAN Index)

Use the VLAN Static Table to configure port members for the selected
VLAN index. Assign ports as tagged if they are connected to 802.1Q
VLAN compliant devices, or untagged they are not connected to any
VLAN-aware devices. Or configure a port as forbidden to prevent the
switch from automatically adding it to a VLAN via the GVRP protocol.
Notes: 1. You can also use the VLAN Static Membership by Port page
Name
DefaultVlan
R&D
to configure VLAN groups based on the port index
(page 3-113). However, note that this configuration page can
only add ports to a VLAN as tagged members.
Status Ports/Channel groups
Active Eth1/ 1 Eth1/ 2 Eth1/ 3 Eth1/ 4 Eth1/ 5
Eth1/ 6 Eth1/ 7 Eth1/ 8 Eth1/ 9 Eth1/10
Eth1/11 Eth1/12 Eth1/13 Eth1/14 Eth1/15
Eth1/16 Eth1/17 Eth1/18 Eth1/19 Eth1/20
Eth1/21 Eth1/22 Eth1/23 Eth1/24 Eth1/25
Eth1/26
Active
VLAN C
ONFIGURATION
4-162
4-163
4-172
3-111
