Configuring Static Arp Addresses - SMC Networks SMC6724L3 Management Manual

C
ONFIGURING THE
Web - Click IP, ARP, General. Set the timeout to a suitable value for the
ARP cache, enable Proxy ARP for subnetworks that do not have routing
or a default gateway, and click Apply.
CLI - This example sets the ARP cache timeout for 15 minutes (i.e., 900
seconds), and enables Proxy ARP for VLAN 3.
Console(config)#arp-timeout 900
Console(config)#interface vlan 3
Console(config-if)#ip proxy-arp
Console(config-if)#

Configuring Static ARP Addresses

For devices that do not respond to ARP requests, traffic will be dropped
because the IP address cannot be mapped to a physical address. If this
occurs, you can manually map an IP address to the corresponding physical
address in the ARP.
Command Usage
• You can define up to 128 static entries in the ARP cache.
• Static entries will not be aged out or deleted when power is reset. You can
only remove a static entry via the configuration interface.
Command Attributes
• IP Address – IP address statically mapped to a physical MAC address.
(Valid IP addresses consist of four numbers, 0 to 255, separated by
periods.)
