3
Configuring the Switch
Web – Click Port, Rate Limit, Input/Output Port/Trunk Configuration. Enable the
Rate Limit Status for the required interfaces, then set the rate limit for the individual
interfaces, and click Apply.
CLI - This example sets the rate limit level for input traffic passing through port 3.
Console(config)#interface ethernet 1/3
Console(config-if)#rate-limit input 500
Console(config-if)#

Showing Port Statistics

You can display standard statistics on network traffic from the Interfaces Group and
Ethernet-like MIBs, as well as a detailed breakdown of traffic based on the RMON
MIB. Interfaces and Ethernet-like statistics display errors on the traffic passing
through each port. This information can be used to identify potential problems with
the switch (such as a faulty port or unusually heavy loading). RMON statistics
provide access to a broad range of statistics, including a total count of different
frame types and sizes passing through each port. All values displayed have been
accumulated since the last system reboot, and are shown as counts per second.
Statistics are refreshed every 60 seconds by default.
Note:
RMON groups 2, 3 and 9 can only be accessed using SNMP management
software such as SMC EliteView.
Parameter
Interface Statistics
Received Octets
Received Unicast Packets
3-130

Figure 3-80 Input Rate Limit Port Configuration

Table 3-11 Port Statistics

Description
The total number of octets received on the interface, including framing
characters.
The number of subnetwork-unicast packets delivered to a higher-layer
protocol.
4-155
4-185
