Goodrive300
Function
code
P05.04 S4 terminals function
P05.05 S5 terminals function
P05.06 S6 terminals function
P05.07 S7 terminals function
S8 terminals function
P05.08
HDI terminals function
P05.09
Name
6: Coast to stop
selection 7: Fault reset
8: Operation pause
9: External fault input
selection
10:Increasing frequency setting(UP)
11:Decreasing
selection
setting(DOWN)
12:Cancel the frequency change setting
selection
13:Shift between A setting and B setting
14:Shift between combination setting
selection
and A setting
15:Shift between combination setting
and B setting
16:Multi-stage speed terminal 1
17:Multi-stage speed terminal 2
18:Multi-stage speed terminal 3
19:Multi- stage speed terminal 4
20:Multi- stage speed pause
21:ACC/DEC time option１
22:ACC/DEC time option２
23:Simple PLC stop reset
24:Simple PLC pause
25:PID control pause
selection
26:Traverse Pause(stop at the current
frequency)
27:Traverse reset(return to the center
frequency)
28:Counter reset
29:Torque control prohibition
30:ACC/DEC prohibition
31:Counter trigger
32:Length reset
33:Cancel the frequency change setting
temporally
34:DC brake
Detailed instruction of parameters
189
Basic operation instruction
Default
value
frequency
0
0
0
0
0
0
