INVT Goodrive 300 Operation Manual page 70

inverters
Goodrive300
Functio
Name
n code
Keypad
P03.12 setting
torque
Torque given
P03.13
filter time
Torque
control
forward
rotation
P03.14
upper-limit
frequency
setting
source
selection
Torque
control
reverse
rotation
P03.15
upper-limit
frequency
keypad
defined value
P03.16 Torque
control
forward
rotation
upper-limit
frequency
Detailed instruction of parameters
8:PROFIBUS communication setting torque
9:Ethernet communication setting torque
10:CAN communication setting torque
Note: 100% of Setting methods 2~10, corresponds
to three times of the rated current of the motor.
Setting range: -300.0%~300.0%(motor rated current) 50.0%
0.000~10.000s
0:keypad setting upper-limit frequency(P03.16 sets
P03.14,P03.17 sets P03.15)
1:Analog AI1 setting upper-limit frequency
2:Analog AI2 setting upper-limit frequency
3:Analog AI3 setting upper-limit frequency
4:Pulse frequency HDI setting upper-limit frequency
5:Multi-stage setting upper-limit frequency
6:MODBUS communication setting upper-limit
frequency
7:PROFIBUS communication setting upper-limit
frequency
8:Ethernet communication setting upper-limit
frequency
9:CAN communication setting upper-limit frequency
Note:setting method 1~9, 100% corresponds to the
maximum frequency
This function is used to set the upper limit of the
frequency. P03.16 sets the value of P03.14; P03.17
sets the value of P03.15.
Setting range:0.00 Hz~P00.03 (the Max. output
frequency)
69
Function codes
Default Modif
value y
○
○
0.100s
○
0
○
0
50.00
○
Hz
