P15 Group Profibus function
P15.00 Module type
Module
P15.01
address
PZD2
P15.02
Receiving
PZD3
P15.03
Receiving
PZD4
P15.04
Receiving
PZD5
P15.05
Receiving
PZD6
P15.06
Receiving
PZD7
P15.07
Receiving
PZD8
P15.08
Receiving
Detailed instruction of parameters
all reading and writing commands of the upper
monitor.
1:Operation without response；The drive only
responds to the reading command other than the
writing command of the drive. The communication
efficiency can be increased by this method.
LED tens:(reserved)
0:Profibus
Select communication protocol
0~127
This function code is used to designate the address
of the inverter.
Note:0 is the broadcast address,when set it as
broadcast address, only receive the radio command
of the upper monitor other than answering the upper
monitor.
0:Invalid
1:Set frequency(0~Fmax(unit:0.01Hz))
2:Given PID, range(0～1000,1000 corresponds to
100.0%)
3:PID feedback, range(0～1000,1000 corresponds
to 100.0%)
4:Torque set value(-3000~3000,1000 corresponds to
100.0% the rated current of the motor)
5:Set value of the forward rotation upper-limit
frequency(0~Fmax unit:0.01Hz))
6:Set value of the reversed rotation upper-limit
frequency(0~Fmax(unit:0.01Hz))
7:Electromotion torque upper limit (0~3000,1000
corresponds to 100.0%of the rated current of the
133
Function codes
Default Modif
value y
●
●
◎
0
◎
2
○
0
○
0
○
0
○
0
○
0
○
0
○
0
