INVT Goodrive 300 Operation Manual page 104

inverters
Goodrive300
Functio
Name
n code
Setting
P08.19
length
P08.20 Actual length
Pulse per
P08.21
rotation
Alxe
P08.22
perimeter
P08.23 Length ratio
Length
P08.24 correcting
coefficient
Setting
P08.25
counting
value
P08.26 Reference
Detailed instruction of parameters
to the sudden jumping frequency.
The raising time of the traverse frequency:The time
from the lowest point to the highest one.
The declining time of the traverse frequency :The
time from the highest point to the lowest one.
The setting range of P08.15: 0.0~100.0%(relative to
the set frequency)
The setting range of P08.16: 0.0~50.0%(relative to
the traverse range)
The setting range of P08.17: 0.1~3600.0s
The setting range of P08.18: 0.1~3600.0s
The function codes of setting length, actual length
and unit pulse are mainly used to control the fixed
length.
The length is counted by the pulse signal of HDI
terminals input and the HDI terminals are needed to
set as the length counting input.
Actual length＝the length counting input pulse /unit
pulse
When the actual length P08.20 exceeds the setting
length P08.19, the multi-function digital output
terminals will output ON.
Setting range of P08.19: 0~65535m
Setting range of P08.20:0~65535m
Setting range of P08.21:1~10000
Setting range of P08.22:0.01~100.00cm
Setting range of P08.23:0.001~10.000
Setting range of P08.24:0.001~1.000
The counter works by the input pulse signals of the
HDI terminals.
When the counter achieves a fixed number, the
multi-function output terminals will output the signal
103
Function codes
Default Modif
value y
○
0m
●
0m
○
1
10.00c
○
m
○
1.000
○
1.000
○
0
○
0
