inverters
Goodrive300
Functio
Name
n code
HDO
high-speed
P06.16
pulse output
selection
Lower limit of
P06.17
AO1 output
P06.18 Correspondi
ng AO1
output to the
Detailed instruction of parameters
2:Ramp reference frequency
3:Running rotation speed
4:Output current (relative to the rated current of the
inverter)
5:Output current(relative to the rated current of the
motor)
6:Output voltage
7:Output power
8:Set torque value
9:Output torque
10:Analog AI1 input value
11:Analog AI2 input value
12:Analog AI3 input value
13:High speed pulse HDI input value
14:MODBUS communication set value 1
15:MODBUS communication set value 2
16:PROFIBUS communication set value 1
17:PROFIBUS communication set value 2
18: Ethernet communication set value 1
19: Ethernet communication set value 2
20: CAN communication set value 1
21: CAN communication set value 2
22:Torque current(relative to the rated current of the
motor)
23:Pre-magnetizing current(relative to the rated
current of the motor)
24:Reserved
The above function codes define the relative
relationship between the output value and analog
output. When the output value exceeds the range of
set maximum or minimum output, it will count
according to the low-limit or upper-limit output.
89
Function codes
Default Modif
value y
○
0
○
0.0%
○
0.00V
