INVT Goodrive 300 Operation Manual page 132

inverters
Goodrive300
Functio
Name
n code
The braking
retention
P13.15
time when
stopping
P14 Group Serial communication
Local
communicati
P14.00
address
Communicati
P14.01
baud ratio
Digital bit
P14.02
checkout
Detailed instruction of parameters
set by P01.12 (refer to the instruction of
P01.09~P01.12) .
Setting range of P13.13: 0.0~150.0%(the inverter)
Setting range of P13.14: 0.0~50.0s
Setting range of P13.15: 0.0~50.0s
The setting range:1~247
When the master is writing the frame, the
communication address of the slave is set to 0; the
address is the communication address. All slaves on
the MODBUS fieldbus can receive the frame, but the
salve doesn't answer.
The communication of the drive is unique in the
communication net. This is the fundamental for the
point to point communication between the upper
monitor and the drive.
Note:The address of the slave cannot set to 0.
Set the digital transmission speed between the
upper monitor and the inverter.
0:1200BPS
1:2400BPS
2:4800BPS
3:9600BPS
4:19200BPS
5:38400BPS
6:57600BPS
7:115200BPS
Note:The baud rate between the upper monitor and
the inverter must be the same. Otherwise, the
communication is not applied. The bigger the baud
rate, the quicker the communication speed.
The data format between the upper monitor and the
inverter must be the same. Otherwise, the
communication is not applied.
131
Function codes
Default Modif
value y
○
0.0s
○
1
○
4
○
1
