INVT Goodrive 300 Operation Manual page 151

inverters
Goodrive300
Function
code
frequency keypad defined
Electromotion torque
P03.18
upper-limit keypad setting
Brake torque upper-limit
P03.19
setting saurce selection
Brake torque upper-limit
P03.20
Weakening coefficience in
P03.21
constant power zone
The loweat weakening
P03.22
coefficient in Constant
P03.23 The loweat weakening
Name
value
keypad setting
power zone
Detailed instruction of parameters
0:Keypad sets the
torque(P03.18 sets the value of P03.16;
P03.19 sets the value of P03.17)
1:Analog AI1 setting torque upper-limit
2:Analog AI2 setting torque upper-limit
3:Analog AI3 setting torque upper-limit
4:Pulse frequency HDI setting torque
upper-limit
5:MODBUS communication
torque upper-limit
6:PROFIBUS communication
torque upper-limit
7: Ethernet communication setting torque
upper-limit
8:CAN communication setting torque
upper-limit
Note:setting means
corresponds to three times of motor
current.
0:Keypad setting upper-limit frequency
(P03.21 setting)
1~8:the same as P03.18
0.0~300.0%(rated current of the motor)
0.1~2.0
10%~100%
150
Basic operation instruction
Default
value
upper-limit of
setting
setting
1~9,100%
180.0%
180.0%
0
0
0.3
20%
