INVT Goodrive 300 Operation Manual page 86

inverters
Goodrive300
Functio
Name
n code
ng setting of
the upper
limit of AI2
AI2 input
P05.41
filter time
Lower limit of
P05.42
AI3
Correspondi
ng setting of
P05.43
the lower
limit of AI3
Middle value
P05.44
of AI3
Correspondi
ng middle
P05.45
setting of
AI3
Upper limit of
P05.46
AI3
Correspondi
ng setting of
P05.47
the upper
limit of AI3
AI3 input
P05.48
filter time
HDI
high-speed
P05.49 pulse input
function
selection
Detailed instruction of parameters
Note: Analog AI1 and AI2 can support 0~10V or
0~20mA input, when AI1 and AI2 selects 0~20mA
input, the corresponding voltage of 20mA is 5V. AI3
can support the output of -10V~+10V.
The setting range of P05.32:0.00V~P05.34
The setting range of P05.33:-100.0%~100.0%
The setting range of P05.34:P05.32~10.00V
The setting range of P05.35:-100.0%~100.0%
The setting range of P05.36:0.000s~10.000s
The setting range of P05.37:0.00V~P05.39
The setting range of P05.38:-100.0%~100.0%
The setting range of P05.39:P05.37~10.00V
The setting range of P05.40:-100.0%~100.0%
The setting range of P05.41:0.000s~10.000s
The setting range of P05.42:-10.00V~P05.44
The setting range of P05.43:-100.0%~100.0%
The setting range of P05.44:P05.42~P05.46
The setting range of P05.45:-100.0%~100.0%
The setting range of P05.46:P05.44~10.00V
The setting range of P05.47:-100.0%~100.0%
The setting range of P05.48:0.000s~10.000s
The function selection when HDI terminals is
high-speed pulse input
0:Frequency setting input, frequency setting source
1:Counter input, high-speed pulse counter input
terminals
2:Length counting input, length counter input
85
Function codes
Default Modif
value y
○
0.100s
○
-10.00V
-100.0
○
%
○
0.00V
○
0.0%
○
10.00V
○
100.0%
○
0.100s
◎
0
