Response xx xx xx xx xx xx
In each request frame contents of PZD3 are given by traction until re-select a parameter.
A.2.9 Fault information
EC-TX-103 communication card is equipped with 2 fault display LEDs as shown is figure
below. The roles of these LEDs are as follows:

Fault display LEDs

LED No. Name
Main
1
display
2 Online
3 Offline
4 Fault
xx xx
Color
Green ON--Connection works
ON-Connection lost for ever
Red
Flashes- Connection lost for temporary
ON-module online and data can be exchanged.
Green
OFF-module is not in "online" state.
ON-module offline and data can't be exchanged.
Red
OFF-module is not in "offline" state.
1. Flicker frequency 1Hz-configuration error: The length of
user parameter data sets is different from that of network
configuration process during module initialization process.
2. Flicker frequency 2Hz-user parameter data error: The
length or content of user parameter data sets is different
Red
from that of network configuration process during module
initialization process.
3. Flicker frequency 4Hz-Profibus communication ASIC
initialization error.
4. OFF-Diagnostic closed.
271
xx xx xx xx 00
Function
Appendix A
00 ... xx xx
