INVT Goodrive 300 Operation Manual page 131

inverters
Goodrive300
Functio
Name
n code
Shift
frequency of
P13.04
source
current
Superposing
P13.05 frequency
(reserved)
P13.06 Pulse
superpositio
n voltage
P13.07 Reserved
P13.08 Reserved
P13.09 Reserved
P13.10 Reserved
Maladjustme
P13.11 nt detection
time
High
frequency
P13.12
compensatio
n coefficient
Braking
P13.13 current of
short-circuit
The braking
retention
P13.14
time before
starting
Detailed instruction of parameters
frequency point of current shifting. There is no need
to modify the value generally.
Setting range: 0.0%~100.0%(rated current of the
motor)
Valid frequency shifting point between source
current 1 and current 2.
Setting range: 0.00Hz~P00.03(the Max. frequency)
200~1000Hz
0.0~300.0%(rated voltage of the motor)
0~65535
0~65535
0~655.35
0~65535
Adjust the response of anti-maladjustment. If the
inertia of the load is bigger, this value may be bigger
too, but the response will be slow.
Setting range: 0.0~10.0s
When the motor runs above the rated rotation speed,
the parameter is valid, if vibration occurs to the
motor, please adjust the parameter.
Setting range: 0~100.0%
When P01.00=0 during the starting of the inverter,
set P13.14 to a non-zero value to enter the short
circuit braking.
When the running frequency is lower than P01.09
during the stopping of the inverter, set 13.15 to a
non-zero value to enter into stopping short circuited
braking and then carry out the DC braking at the time
130
Function codes
Default Modif
value y
10.00
○
Hz
◎
500Hz
◎
40.0%
○
0
○
0
○
2.00
○
0
○
0.5s
○
0.0%
○
0.0%
○
0.0s
