INVT Goodrive 300 Operation Manual page 166

inverters
Goodrive300
Function
code
rated power rotor resistor
Asynchronous motor 1
P02.08
Asynchronous motor
P02.09
Asynchronous motor 1
P02.10
Synchronous motor 1
P02.15
Synchronous motor 1
P02.16
Synchronous motor 1
P02.17
number of poles pairs
Synchronous motor 1
P02.18
Synchronous motor 1
P02.19
Synchronous motor 1
P02.20
Synchronous motor 1
P02.21
direct axis inductance
Synchronous motor 1
P02.22
P02.23 Synchronous motor 1
Multi-function digital input
P05.01~P0
5.09 (S1~S8, HDI) function
The shifting channel
P08.31 between motor 1 and
Name
magnetic leakage
1mutual inductance
non-load current
rated power
rated frequency
rated voltage
rated current
stator resistor
quadrature axis
inductance
Back EMF constant
terminals
selection
motor 2
Detailed instruction of parameters
0.1~6553.5mH
0.1~6553.5mH
0.1~6553.5A
0.1~3000.0kW
0.01Hz~P00.03(the Max. frequency)
1~50
0~1200V
0.8~6000.0A
0.001~65.535Ω
0.1~6553.5mH
0.1~6553.5mH
0~10000
35: Shift from motor 1 to motor 2
LED ones:
0: terminal shifting; digital terminal is 35
1: MODBUS communication shifting
2: PROFIBUS communication shifting
165
Basic operation instruction
Default
value
on model
Depend
on model
Depend
on model
Depend
on model
Depend
on model
50.00Hz
Depend
on model
Depend
on model
Depend
on model
Depend
on model
Depend
on model
300
2
0
