Nameplate; Type Designation Key - INVT Goodrive 300 Operation Manual

inverters
Goodrive300
Function
Relay output
Mountable method
Temperature of the
running environment
Average non-fault
Protective degree
Others
Braking unit

3.4 Nameplate

3.5 Type designation key

The type designation contains information on the inverter. The user can find the type
designation on the type designation label attached to the inverter or the simple name plate.
2 ways programmable relay output
RO1A NO, RO1B NC, RO1C common terminal
RO2A NO, RO2B NC, RO2C common terminal
Contactor capability: 3A/AC250V,1A/DC30V
Wall, flange and floor mountable
-10~50℃, derate above 40℃
2 years (25℃ ambient temperature)
time
IP20
Cooling Air-cooling
Built in braking unit for below 30kW (including
30kW)
External braking unit for others
Built-in C3 filter: meet the degree requirement of
IEC61800-3 C3
EMC filter
External filter:meet the degree requirement of
IEC61800-3 C2
Fig 3-3 Name plate
Specification
17
Product overview
