Structure Diagram - INVT Goodrive 300 Operation Manual

inverters
Goodrive300
The inverter
GD300-090G-4
GD300-110G-4
GD300-132G-4
GD300-160G-4
GD300-200G-4
GD300-220G-4
GD300-250G-4
GD300-280G-4
GD300-315G-4
GD300-350G-4
GD300-400G-4
GD300-500G-4
Note:
1. The input current of 1.5~315kW inverters is measured when the input voltage is 380V and
configured without DC reactor and input/output filter.
2. The input current of 350~500kW inverters is measured when the input voltage is 380V
and configured with input reactor.
3. The output current is defined as the output current when the output voltage is 380V.
Note: the inverter is configured LED keypad. The LCD keypad is optional with various
functions. The installation is compatible with that of the LED keypad.
Note: M3 nuts and the bracket can be used directly in the installation. The keypad bracket is
optional for 1.5~30kW inverters and configured for 37~500kW inverters.

3.7 Structure diagram

Below is the layout figure of the inverter (take the inverter of 30kW as the example).
Constant torque
Rated Rated
output input
power (A) current (A)
90 190
110 225
132 265
160 310
200 385
220 430
250 485
280 545
315 610
350 625
400 715
500 890
Rated
output
current (A)
180
215
260
305
380
425
480
530
600
650
720
860
19
Product overview
Weight(Kg)
Weight(Kg)
90
110
132
160
200
220
250
280
315
350
400
500
