INVT Goodrive 300 Operation Manual page 95

inverters
Goodrive300
Functio
Name
n code
The
parameter 2
P07.06
in running
state
The
parameter in
P07.07
the stop
state
Detailed instruction of parameters
BIT14:length value
BIT15:PLC and the current stage in multi-stage
speed
0x0000~0xFFFF
BIT0: analog AI1 value (V on)
BIT1: analog AI2 value (V on)
BIT2: analog AI3 value (V on)
BIT3: high speed pulse HDI frequency
BIT4: motor overload percentage (% on)
BIT5: the inverter overload percentage (% on)
BIT6: ramp frequency given value(Hz on)
BIT7: linear speed
BIT8: AC inlet current (A on)
BIT9~15:reserved
0x0000~0xFFFF
BIT0:set frequency(Hz on, frequency flickering
slowly)
BIT1:bus voltage (V on)
BIT2:input terminals state
BIT3:output terminals state
BIT4:PID reference (% flickering)
BIT5:PID feedback value(% flickering)
BIT6:torque reference(% flickering)
BIT7:analog AI1 value(V on)
BIT8:analog AI2 value(V on)
BIT9: analog AI3 value(V on)
BIT10:high speed pulse HDI frequency
BIT11:PLC and the current stage in multi-stage
speed
BIT12:pulse counters
BIT13:length value
BIT14~BIT15:reserved
94
Function codes
Default Modif
value y
0x0000
○
0x00FF
