INVT Goodrive 300 Operation Manual page 103

inverters
Goodrive300
Functio
Name
n code
Jumping
P08.14 frequency
range 3
Traverse
P08.15
range
Sudden
jumping
P08.16
frequency
range
Traverse
P08.17
boost time
Traverse
P08.18
declining
time
Detailed instruction of parameters
Setting range: 0.00~P00.03(the Max. frequency)
This function applies to the industries where traverse
and convolution function are required such as textile
and chemical fiber.
The traverse function means that the output
frequency of the inverter is fluctuated with the set
frequency as its center. The route of the running
frequency is illustrated as below, of which the
traverse is set by P08.15 and when P08.15 is set as
0, the traverse is 0 with no function.
Traverse range:The traverse running is limited by
upper and low frequency.
The traverse range relative to the center frequency:
traverse range AW＝center frequency×traverse
range P08.15.
Sudden jumping frequency＝traverse range AW×
sudden jumping frequency range P08.16. When run
at the traverse frequency, the value which is relative
102
Function codes
Default Modif
value y
○
0.00Hz
○
0.0%
○
0.0%
○
5.0s
○
5.0s
