INVT Goodrive 300 Operation Manual page 107

inverters
Goodrive300
Functio
Name
n code
value
Frequency
arrival
P08.36
detection
value
Energy
braking
P08.37
enable
Threshold
P08.38
voltage
Detailed instruction of parameters
frequency)
Setting range of P08.33: 0.0~100.0%(FDT1
electrical level)
Setting range of P08.34: 0.00~P00.03(the Max.
frequency)
Setting range of P08.35: 0.0~100.0%(FDT2
electrical level)
When the output frequency is among the below or
above the range of the set frequency, the
multi-function digital output terminal will output the
signal of "frequency arrival", see the diagram below
for detailed information:
The setting range:0.00Hz~P00.03(the Max.
frequency)
This parameter is used to control the internal braking
pipe inside the inverter.
0:Disable
1:Enable
Note:Only applied to internal braking pipe.
After set the original bus voltage to brake the
energy, brake the load by adjusting the voltage
appropriately. The factory changes with voltage
106
Function codes
Default Modif
value y
○
0.00Hz
○
0
220V
○
voltage:3
80.0V
