INVT Goodrive 300 Operation Manual page 43

inverters
Goodrive300
Seri Name
al
No.
Digital
4 potentiom Tuning frequency. Please refer to P08.41.
eter
5 Buttons
Description
9
C
F
L
o
S
v
Enter or escape from the first level
Programming key menu
quickly
Enter the menu step-by-step
Entry key
Confirm parameters
Increase data or function code
UP key
progressively
Decrease data or function code
DOWN key
progressively
Move right to select the displaying
parameter circularly in stopping and
Right-shift key running mode.
Select the parameter modifying digit
during the parameter modification
This key is used to operate on the
Run key
inverter in key operation mode
Stop/ This key is used to stop in running state
Reset key and it is limited by function code P07.04
This key is used to reset all control
42
Keypad operation procedure
A
d
H
N
P
t
.
and remove the parameter
B
E
I
n
r
U
-
