INVT Goodrive 300 Operation Manual page 71

inverters
Goodrive300
Functio
Name
n code
keypad
defined value
Torque
control
reverse
rotation
P03.17
upper-limit
frequency
keypad
defined value
Electromotio
n torque
upper-limit
P03.18
setting
source
selection
Braking
torque
upper-limit
P03.19
setting
source
selection
Electromotio
n torque
P03.20
upper-limit
keypad
setting
Detailed instruction of parameters
This function code is used to select the
electromotion and braking torque upper-limit setting
source selection.
0:Keypad setting upper-limit frequency(P03.20 sets
P03.18,P03.21 sets P03.19)
1:Analog AI1 setting upper-limit torque
2:Analog AI2 setting upper-limit torque
3:Analog AI3 setting upper-limit torque
4:Pulse frequency HDI setting upper-limit torque
5:MODBUS communication setting upper-limit
torque
6:PROFIBUS communication setting upper-limit
torque
7:Ethernet communication setting upper-limit torque
8:CAN communication setting upper-limit torque
Note:setting method 1~9,100% corresponds to three
times of the motor current.
The function code is used to set the limit of the
torque.
Setting range:0.0~300.0%(motor rated current)
70
Function codes
Default Modif
value y
50.00
○
Hz
○
0
○
0
○
180.0%
