INVT Goodrive 300 Operation Manual page 89

inverters
Goodrive300
Functio
Name
n code
Y
P06.06 switching-on
delay time
Y
P06.07 switching-off
delay time
HDO
P06.08 switching-on
delay time
HDO
P06.09 switching-off
delay time
RO1
P06.10 switching-on
delay time
RO1
P06.11 switching-off
delay time
RO2
P06.12 switching-on
delay time
RO2
P06.13 switching-off
delay time
P06.14 AO1 output
P06.15 AO2 output
Detailed instruction of parameters
When the current bit is set to 1, input terminal is
negative.
BIT0 BIT1
Y HDO
Setting range:00~0F
The function code defines the corresponding delay
time of the electrical level change during the
programmable terminal switching on and off.
The setting range :0.000~50.000s
Note: P06.08 and P06.08 are valid only when
P06.00=1.
0:Running frequency
1:Set frequency
BIT2 BIT3
RO1 RO2
88
Function codes
Default Modif
value y
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0
○
0
