inverters Keypad operation procedure
Goodrive300
Remarks: Press both the PRG/ESC and the DATA/ENT can return to the second-level menu
from the third-level menu. The difference is: pressing DATA/ENT will save the set
parameters into the control panel, and then return to the second-level menu with shifting to
the next function code automatically; while pressing PRG/ESC will directly return to the
second-level menu without saving the parameters, and keep staying at the current function
code.
Under the third-level menu, if the parameter has no flickering bit, it means the function code
cannot be modified. The possible reasons could be:
1) This function code is not modifiable parameter, such as actual detected parameter,
operation records and so on;
2) This function code is not modifiable in running state, but modifiable in stop state.
Example:Set function code P00.01 from 0 to 1.
Fig 5-2 Sketch map of modifying parameters

5.4.2 How to set the password of the inverter

Goodrive300 series inverters provide password protection function to users. Set P7.00 to
gain the password and the password protection becomes valid instantly after quitting from
the function code editing state. Press PRG/ESC again to the function code editing state,
"0.0.0.0.0" will be displayed. Unless using the correct password, the operators cannot enter
it.
Set P7.00 to 0 to cancel password protection function.
The password protection becomes effective instantly after retreating form the function code
editing state. Press PRG/ESC again to the function code editing state, "0.0.0.0.0" will be
