5.3 Keypad displaying

The keypad displaying state of Goodrive300 series inverters is divided into stopping state
parameter, running state parameter, function code parameter editing state and fault alarm
state and so on.

5.3.1 Displayed state of stopping parameter

When the inverter is in the stopping state, the keypad will display stopping parameters which
is shown in figure 5-2.
In the stopping state, various kinds of parameters can be displayed. Select the parameters
to be displayed or not by P07.07. See the instructions of P07.07 for the detailed definition of
each bit.
In the stopping state, there are 14 stopping parameters can be selected to be displayed or
not. They are: set frequency, bus voltage, input terminals state, output terminals state, PID
given value, PID feedback value, torque set value, AI1, AI2, AI3, HDI, PLC and the current
stage of multi-stage speeds, pulse counting value, length value. P07.07 can select the
parameter to be displayed or not by bit and》 /SHIFT can shift the parameters form left to right,
QUICK/JOG(P07.02=2) can shift the parameters form right to left.

5.3.2 Displayed state of running parameters

After the inverter receives valid running commands, the inverter will enter into the running
state and the keypad will display the running parameters. RUN/TUNE LED on the keypad is
on, while the FWD/REV is determined by the current running direction which is shown as
figure 5-2.
In the running state, there are 24 parameters can be selected to be displayed or not. They
are: running frequency, set frequency, bus voltage, output voltage, output torque, PID given
value, PID feedback value, input terminals state, output terminals state, torque set value,
length value, PLC and the current stage of multi-stage speeds, pulse counting value, AI1,
AI2, AI3, HDI, percentage of motor overload, percentage of inverter overload, ramp given
Description
modes in the fault alarm state
The function of this key is confirmed by
Quick key
function code P07.02.
43
