INVT Goodrive 300 Operation Manual page 195

inverters
Goodrive300
Set value
POROFIBUS communication
24
virtual terminal output
25~30
Relative parameters list:
Function
code
P06.00
P06.01
P06.02 HDO output selection
P06.03
P06.04
Function
Reserved
Name
HDO output type
Y output selection
Relay RO1 output
selection
Relay RO2 output
selection
Output corresponding signal according to the
setting value of PROFIBUS. Output ON signal if the
setting value is 1 and output OFF signal if the
setting value is 0.
Detailed instruction of parameters
0:Open collector pole high speed pulse
output
1: Open collector pole output
0:Invalid
1:On operation
2:Forward rotation operation
3:Reverse rotation operation
4: Jogging operation
5:The inverter fault
6:FDT1
7:FDT2
8:Frequency arrival
9:Zero speed running
10:Upper limit frequency arrival
11:Lower limit frequency arrival
12:Ready for operation
13:Pre-magnetizing
14:Ooverload pre-alarm
15: Uunderload pre-alarm
16:Ccompletion of simple PLC stage
17:Completion of simple PLC cycle
18:Setting count value arrival
19:Defined count value arrival
20:External fault valid
21:Length arrival
22:Running time arrival
23:MODBUS communication
194
Basic operation instruction
Instructions
virtual
Default
value
0
0
0
1
5
