Functio
Name
n code
Keypad PID
P09.01
preset
PID
feedback
P09.02
source
PID output
P09.03
feature
Detailed instruction of parameters
7:PROFIBUS communication set
8:Ethernet communication set
9:CAN communication set
The setting target of procedure PID is a relative one,
100% of the setting equals to 100% of the response
of the controlled system.
The system is calculated according to the relative
value (0~100.0%).
Note:
Multi-stage speed given,it is realized by
setting PA group parameters.
PROFIBUS communication setting,
communication setting and CAN communication
setting need more corresponding extension cards.
When P09.00=0,set the parameter whose basic
value is the response value of the system.
The setting range:-100.0%~100.0%
Select the PID channel by the parameter.
0:Analog channel AI1 feedback
1:Analog channel AI2 feedback
2:Analog channel AI3 feedback
3:High speed HDI feedback
4:MODBUS communication feedback
5:PROFIBUS communication feedback
6:Ethernet communication feedback
7:CAN communication feedback
Note:The given channel and the feedback channel
can not coincide, otherwise, PID can not control
effectively.
0:PID output is positive:When the feedback signal
exceeds the PID given value, the output frequency of
the inverter will decrease to balance the PID. For
Ethernet
111
Function codes
Default Modif
value y
○
0.0%
○
0
○
0
